Model No: TS-CWXX10-40C
1310nm-TX/1550nm-RX Simplex LC Bidi Fiber Optic Transceivers Module Single Mode Dual-Fiber 1G/10G/25G SFP 20km
minimum order :
2 pieces
Stock Time :
7Day
Quantity :
- Model Number:TS-CWXX10-40C
- Type:Fiber Optic Transceivers
- Place of Origin:Guangdong, China
- Brand Name:Jiaxun
- Use:Industrial network
- Warranty Time:5
- Network:Wired LAN
- Application:Network Solution
- Model:Single Mode
- Fiber Type:SMF
- Product name:10G SFP+ Module
- Wavelength:1270-1610nm
- Connector Type:LC-LC
- Warranty:5 years
- Working temperature:0-70C
Product Description
Item | 10G SFP+ Module |
Vendor Name | Jiaxun |
Part Status | Active |
Form Factor | SFP+ |
Max Data Rate | 10Gbps |
Max Cable Distance | 10KM |
Wavelength | 1270-1610nm |
Connector | Duplex LC |
Media | SMF |
TX Power | -7.3~-1dBm |
Receiver Sensitivity | ＜-11.1dBm |
Receiver Overload | -1dBm |
Power Consumption | ≤1w |
DDM/DOM | DDM Supported |
Commercial Temperature Range | 0 to 70°C |
Protocols | IEEE 802.3ae, SFF-8472, SFF-8431, SFF-8432,SFP+ MSA Compliant, CPRI, eCPRI |
Warranty | 5 Years |
Sample | Available |
