Model No: JS-CW271G-20C

SFP 1.25G 1270nm Single LC 20Km SMF Optical Transceiver Multimode CWDM Fiber Modules

minimum order :

2 pieces

Stock Time :

7Day

add to cart

Contact Now

Model Number:TS-CW271G-20C
Type:Fiber opitc adapter
Place of Origin:Guangdong, China
Brand Name:Jiaxun
Use:Industrial network
Warranty Time:5
Network:Wired LAN
Application:Network Solution
Model:Single Model
Fiber Type:SMF
Product name:1.25G SFP Module
Wavelength:1270nm
Connector Type:LC-LC
Warranty:5 years
Working temperature:0-70C

Product Description

Item	1.25G SFP Module
Vendor Name	Jiaxun
Part Status	Active
Form Factor	SFP
Max Data Rate	1.25Gbps
Max Cable Distance	20KM
Wavelength	1270nm
Connector	Duplex LC
Media	SMF
TX Power	-9.5 ~ - 3dBm
Receiver Sensitivity	< -17dBm
Receiver Overload	-3dBm
Power Consumption	≤0.8W
DDM/DOM	DDM Supported
Commercial Temperature Range	0 to 70°C (32 to 158°F)
Protocols	IEEE 802.3z, SFF-8472, SFP MSA (INF-8074i) Compliant
Warranty	5 Years
Sample	Available
