Model No: TE 1-1840012-2
TE 1-1840012-2 Compatible JIAXUN 1000 Base-T RJ45 MagJack with Single USB Tab Up Orange&Green/Yellow Leds
The TE 1-1840012-2 Compatible supports speed 100/1000 Base-T, It is compliant to IEEE 802.3, UL, Reach, RoHs, ISO19001,ISO14001 standards.It can be used to support application, such as Smart Camera, Monitoring System,1/0 Controller and Alarm.
Delivery :
EXW
minimum order :
2 pieces
Supply Ability :
5000000pieces / Month
Stock Time :
7Day
Country of Origin :
Guangdong, China
TE 1-1840012-2 Compatible JIAXUN 100/1000Base-T Single USB RJ45 Magjack (Tab Up ,Orange&Green/Yellow LED)
The TE 1-1840012-2 Compatible supports speed 100/1000 Base-T, It is compliant to IEEE 802.3, UL, Reach, RoHs, ISO19001,ISO14001 standards.It can be used to support application, such as Smart Camera, Monitoring System,1/0 Controller and Alarm.
| Tyco Compatible | 1840024-2 | Vendor Name | JIAXUN |
| Connector Type | Jack | Mounting Type | Through Hole |
| Number of Positions/Contacts | 8p8c(RJ45, Ethernet) | Application-Lan | Ethernet(Non PoE) |
| Number of Ports | Single Port with Dual USB | Speed | 10/100/1000 Base-T |
| Latch | Up | Cores per Port | 4 |
| Orientation | 90° Angle (Right) | PCB Mount Angle | SIDE ENTRY |
| Shield EMI Tabs | With | LED Option | Orange&Green/Yellow Leds |
| PCB | FR4 | PCB Retaining Post | T POST |
| Package Height (Inches/mm) | 0.822/20.89 | Package Length (Inches/mm) | 1.142/29.00 |
| Package Width (Inches/mm) | 0.654/16.60 | Temperature | -40℃ to 85℃ |
| Bst Circuit | Yes | AutomDX | Yes |
| Diodes | No | Contact Mating Area Plating | GOLD 6u"/15u"/30u" |
| Turns Ratio RX/TX | 1CT:1CT | Configuration RX/TX | T、C |
