Model No: JS-SM551G-A2I
1.25G SFP 1550nm 120km DDM Duplex LC/UPC SMF Optical Transceiver Module(Industrial)
Delivery :
EXW
minimum order :
2 pieces
Supply Ability :
500000pieces / Month
Stock Time :
7Day
Country of Origin :
Guangdong.China
Quantity :
JIAXUN JS-SM551G-A2I 1.25G SFP Duplex LC/UPC Optical Transceiver Module(SMF, 1550nm, 120km, LC, DOM, Industrial)
The JS-SM551G-A2I SFP transceivers are high performance, cost effective modules supporting data rate of 1.25Gbps and 120km transmission distance with SMF. The transceiver consists of three sections: a FP laser transmitter, a PIN photodiode integrated with a transimpedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements. The transceivers are compatible with SFP Multi-Source Agreement and SFF-8472 digital diagnostics functions.
| JIAXUN Part Number | JS-SM551G-A2I | Vendor Name | JIAXUN |
| Form Factor | SFP | Max Data Rate | 1.25Gbps |
| Wavelength | 1550nm | Max Cable Distance | 120km |
| Connector | Duplex LC | Optical Components | DFB 1550nm |
| Media | SMF | DOM Support | Yes |
| TX Power | 0 to +5dBm | RX Power | -30 to -1dBm |
| Receiver Sensitivity | -28dBm | Receiver Overload | -1dBm |
| Operating case temperature | 0 to 70°C | Protocols | SFF-8472 MSA Compliant, IEEE 802.3ah-2004 |
Keyword1.25G SFP Optical Transceiver Module,1.25G SFP Module,1.25G SFP Optical Transceiver,SFP Optical Transceiver
