Cisco C28 DWDM-SFP10G-54.94-I Compatible SFP+ 10G DWDM 1554.94nm 100GHz 40km DOM Duplex LC/UPC SMF Optical Transceiver Module for Transmission (Industrial)
2025-03-24
The SFP+ transceiver supports up to 40km link lengths over single-mode fiber (SMF) via an LC duplex connector. This transceiver is compliant with SFF-8431 and SFF-8432 MSA standards. Digital diagnostics functions are available via a 2-wire serial interface, as specified in SFF-8472, to allow access to real-time operating parameters. With these features, this easy to install, hot swappable transceiver is suitable to be deployed in the DWDM networking equipment in metropolitan access and core networks.
| Form Factor | SFP+ | Max Data Rate | 10Gbps | |
| Wavelength | 1554.94nm | Max Cable Distance | 40km | |
| Connector | Duplex LC | Media | SMF | |
| Optical Components | EML DWDM | DOM Support | Yes | |
| TX Power | -1 to +2dBm | RX Power | -16 to -1dBm | |
| Receiver Sensitivity | -15.5dBm | Receiver Overload | 0.5dBm | |
| Commercial temperature Range | -40 to 85°C | Protocols | SFP+ MSA Compliant, CPRI, eCPRI |
