RJ45 connector and lan transformer factory
2025-03-18
| Part Status | Active | Mounting Type | Through Hole |
| Number of Positions/Contacts | 10p8c (RJ45, Ethernet) | Application-Lan | Ethernet(PoE+) |
| Number of Ports | 2x4 Port | Speed | 10/100/1000 Base-T |
| Latch | Both | Cores per Port | 8 |
| Orientation | 90° Angle (Right) | PCB Mount Angle |
SIDE ENTRY |
| Shield EMI Tabs | With | LED Option |
Yellow&Green/Yellow&Green |
| PCB | FR4 | PCB Retaining Post |
T POST |
| Package Height (Inches/mm) | 1.015/25.79 | Package Length (Inches/mm) |
1.517/38.53 |
| Package Width (Inches/mm) | 2.330/59.18 | Temperature | -40℃ TO 85℃ |
| Bst Circuit | Yes | AutomDX |
YES |
| Diodes | No | Contact Mating Area Plating |
GOLD 6u"/15u"/30u" |
| Turns Ratio RX/TX | 1CT:1CT | Configuration RX/TX |
T,C |
